Spectral Radiometer
Smart Spectral Radiometer
- Features
- One-click sharing enables parameter testing, analysis, and verification tailored to real-world application scenarios.
- Conduct light source parameter sampling and measurement anytime, anywhere, with the capability to connect to PC software for efficient data analysis and processing.
- With exceptional measurement linearity and accuracy, it is widely used in lighting measurement for homes, shopping malls, schools, factories, greenhouses, and outdoor environments.
Description
Product Introduction
Testing Methods
Smart Spectral Radiometer supports the following testing methods:
- Button testing
- Touchscreen testing
Side Power Button Operation
If the interface selects the first option "Continuous Test":
- Press the power button once to stop the test.
- Press the "Continuous Test" button again to start the test.
If the interface selects the second option "Single Test":
- Press the power button once to stop the test.
- Press the "Single Test" button again to perform the test.
iboson Intelligent Spectral Illuminance Meter
Overview
The iboson Smart Spectral Power Meter is a new generation of handheld light source color testing instruments. It combines advanced micro-spectrometer, embedded operating system, and microcomputer technologies, making testing more convenient and straightforward. With one-click sharing, it aligns perfectly with field applications for parameter testing, analysis, and verification. It enables light source parameter sampling anytime, anywhere, and can be connected to PC software for efficient data analysis and processing. It features excellent measurement linearity and accuracy and is widely used for lighting measurements in homes, malls, schools, factories, greenhouses, and outdoor environments. It is also suitable for light source product development and quality control in production lines. (Bluetooth mini-program version available)
Applicable Standards: GB 40070-2021, JJG_245-2018, GB55016-2021, GB/T 5702-2019, GB/T 5699-2017, GBT 5700-2008, GBT 24824-2009, GB30734-2014, GBT 9473-2017, and other lighting standards.
Main Test Parameters
- Color Temperature (K)
- Illuminance (lx)
- Color Rendering Index (Ra)
- Wavelength (nm)
- Color Coordinate Diagram: CIE1976, CIE1960, CIE1931
- Color Tolerance (SDCM, MacAdam Ellipse, Rectangle Frame, and CIEu’v’ Circle)
- Color Purity, Tristimulus Values X, Y, Z
Product Features
- Utilizes advanced micro-spectrometer technology for higher accuracy than traditional probes
- 3.5-inch IPS touchscreen
- Supports USB and Bluetooth communication
- Built-in 4000mAh lithium battery with ultra-long usage time of over 12 hours
Technical Specifications
| Parameter | Specification |
|---|---|
| Wavelength Range | 380nm–780nm |
| Spectral Resolution | 0.2nm |
| Illuminance Accuracy | ±4% |
| Color Rendering Accuracy | ±1.5% |
| Sensor Area | Ф10mm |
| Color Temperature Range | 1,000K~100,000K |
| Stray Light | ≤0.3% |
| Illuminance Measurement Range | 0.1~200K lx |
| Measurement Mode | Single Test/Continuous Test |
| Spectrum Display Mode | Spectral Distribution Diagram |
| Integration Time | 50μs~10000ms |
| Overall Structure | Fully Aluminum Alloy with Laser Engraving |
| Main Unit Size/Weight | H 115mm | W 58mm | T 18mm / Approx. 200g (Including Battery, excluding accessories) |
Additional Information
The smart spectral radiometer can connect to a computer for data analysis and report generation, supporting PDF and Excel file formats, making it ideal for R&D and quality inspection applications.
Above: Example of Test Data Diagram
