RIGO801 Near-field Optics - Light Ray Chromatic Luminance Distribution RAY FILE Measurement System
RIGO801 MEASURING SOFTWARE
- Features
- Functions of the RiGO801 measurement program
- Measurement of luminous intensity distributions with the camera (near-field mode) or with the photometer (far-field mode)
- Ray file measurements
- Goniospectrometric measurements according to IES LM-79-19, EN 13032-4 or CIE S 025 (spectroradiometer option)
- Logging of the stabilization process and automatic start of the measurement
- Easy alignment of the measurement objects using the measurement camera
- Angular resolution up to 0.1°
- Logging of measured values from external measuring devices (e.g. power analyzer or data logger)
- Batch processing of multiple measurements
- Saving the LID in TechnoTeam format (.TTL), LDT and IES
- Saving of ray data in TechnoTeam format (.TTR). Conversion to various standard formats using the Converter801 program
Description
For the further evaluation of the measured luminous intensity distributions and for report generation, the photometric database software LumCAT from Czibula & Grundmann GbR is used.
Basic features of LUMCat
- Conversion of the LID data from the TechnoTeam format into other formats (EULUM-DAT, TM14, IES, Calculux, ...)
- Function for rotating, tilting and swiveling the light intensity distributions
- Output of luminous intensity distribution (polar, Cartesian, cone diagram)
- Glare rating according to UGR
- Isolux charts
- Report generation
For more information, please refer to the manufacturers Website http://www.lumcat.com.
