Colorimeter

Colorimeter 27 mm wide-angle

Admesy Colorimeter


Colorimeter 27 mm wide-angle

0.0001 - 2 800 cd/m²




Fastest and accurate

PCM2X-271 device

Presenting the next-generation colorimeter, built for rapid and precise display calibration in a rugged, durable design. Equipped with a 5mm spot size, it ensures accurate color measurements for fast adjustments on displays, monitors, and screens.

Its compact and intuitive design makes it an ideal choice for professionals who need a cost-effective yet high-performance solution.

Highlights
Specification
Software
Insights
  • staggering low luminance values, down to 0.0001 cd/m² in just 1 second
  • Collimated lens → allow different measurement distances
  • CIE 1931 or CIE 170-2:2015 CMF available
  • Flicker measurement (2000, 3000 or 3125 samples/sec)
  • Auto-range function
PCM2X-271 device
Luminance range [cd/m²] 0.0001 - 2 800 cd/m²
Chromaticity range [cd/m²] 0.001 cd/m² - 2 800 cd/m²
UHL mode[cd/m²] 20 000 cd/m²
Acceptance angle 9° (± 4.5°)
Measurement spot size 29 mm at 25 mm WD
Firmware Prometheus & PCM2 Colorimeter
Manual Prometheus Colorimeter
Software Prometheus Suite for Windows and macOS
  Libusbmtc driver for Windows (alternative driver for Calman and ColourSpace)
Application Note Choosing a Spectrometer or a Colorimeter for Display Measurement
